CXW-220-A610

● Siphon-Technology to exhaust fumes from all directions

● Aesthetics design

● Patent A++ filter effectively traps heavy oil greases

● 100% dishwasher-safe filter

● Suitable for under cabinet and wall-mount installs

● Non-disessambly and wash free system

● One minute delay off to exhaust out the oil fumes

Contact Us

Technical Parameter

Model	CXW-220-A610
Noise	A609:≤57dB A610:≤58dB
Rated Whole Machine input power	A609:204W A610:224W
Power Supply	220-240V~ 50Hz
Rated Main Motor input power	A609:200W A610:220W
Total Pressure Eficiency	≥23%
Max lighting power	≤2WX2
Nominal Pressure	≥290Pa
Dimensions(WxDxH)	595x350x569(mm)
Air Flow Rate	17 m/min
Net weight	19kg
Maximum Static Pressure	400Pa
Grease Separation Rate	≥92%
Normal Odor Reduction Degree	≥98%
Instantaneous Odor Reduction Degree	≥80%
